SECTION 8—ARMS
Part No 1125104 51 ProSPIN™ X4™
Adjusting T-Arm Width
NOTE:Forthisprocedure,refertoFIGURE8.5.
1. Removethetwomountingscrewsthat
securethearmpadtothearmtube.
2. Turnthearmpadaroundand
repositionthearmpadonthearmtube.
3. Re‐securethearmpadtothearmtube
withthetwomountingscrews.Tighten
securely.
4. Repeatfortheoppositeside,if
necessary.
FIGURE 8.5 Adjusting T-Arm Width
Adjusting T-Arm Depth
NOTE:Forthisprocedure,refertoFIGURE8.6.
1. Removethetwomountingscrewsthatsecurethearmpadtothearmtube.
2. RemovethetwoshortmountingscrewsthatsecurethearmtubetotheT‐armpost.
3. RepositionthearmtubeontheT‐armposttooneofthefollowingpositions:
•DeskLengthArms‐tooneofthree
positionsdependingonthedesired
armpaddepth.
•FullLengthArms‐tooneoffive
positionsdependingonthedesired
armpaddepth.
NOTE:Twoadditionalpositions areobtainable
byturningthearmtube180°.
4. Re‐securethearmtubetotheT‐arm

postwiththetwosocketscrews.
Torqueto60‐70in.‐lbs.
5. Reattachthearmpadtothearmtube
withthetwomountingscrews.Tighten
securely.
6. Repeatfortheoppositeside,if
necessary.
FIGURE 8.6 Adjusting T-Arm Depth
Mounting
Screw
Arm Tube
Mounting
Screw
Arm Pad
Short
Mounting
Screws
Arm Pad
Mounting
Screw
T-Arm Post
Arm Tube
Mounting Screw
