SECTION 11—WHEELS
ProSPIN™ X4™ 78 Part No 1125104
Replacing Non-Projection Handrims - Composite Rear
Wheels
NOTE:Forthisprocedure,refertoFIGURE11.11.
1. Removetherearwheelfromthewheelchair.RefertoRemoving/InstallingRear
Wheelsonpage 67.
2. Removethebuttonscrewsandwashersthatsecurethehandrimtotherearwheel.
3. Removetheexistinghandrimfromtherearwheel.
4. Installthenewhandrimbyreversingtheaboveprocedures.
 WARNING
Make sure detent pin and locking pins of
the quick/quad-release axles are fully
released before operating wheelchair.
5. Reinstallrearwheeltothewheelchair.
RefertoRemoving/InstallingRear
Wheelsonpage 67.
6. Repeattheprocedurefortheopposite
rearwheelifnecessary.
FIGURE 11.11 Replacing Non-Projection
Handrims - Composite Rear Wheels
Repairing/Replacing Pneumatic Tire/Tube
 WARNING
Replacement of a pneumatic tire or tube MUST be performed by a qualified
technician.
CAUTION
As with any vehicle, the wheels, casters and tires should be checked periodically for
cracks and wear, and should be replaced.
Mounting Screws
and Washers
Rear Wheel
Handrim
