SECTION 11—WHEELS
Part No 1125104 77 ProSPIN™ X4™
6. Installoneofthemountingscrewsthroughthemountingholesintherimand
mountingtab.
7. Whilecarefullyholdingthetireandrimstriptooneside,holdthemountingscrew
andsecurelytightenthelocknutthatsecurethehandrimtotherim.
8. RepeatSTEPS6‐7fortheremainingmountingscrewsandlocknuts.
 WARNING
DO NOT inflate tire until handrim is completely assembled.
9. Inflatethetiretothecorrectpsiratingonthesidewallofthetire.
10. Reinstalltherearwheelontothewheelchair.RefertoRemoving/InstallingRear
Wheelsonpage 67.
11. RepeatSTEPS1‐10fortheoppositerearwheelifnecessary.
FIGURE 11.10 Replacing/Adjusting the Handrims - Spoke Rear Wheels
Mounting Screw
Locknut
Rim
(Mounting Hole)
Inside Mounting
Position
Handrim
Mounting Tab
Mounting Tab
Outside Mounting
Position
