SECTION 9—BACK
Part No 1125104 57 ProSPIN™ X4™
Adjusting the Back Height
NOTE:Forthisprocedure,refertoFIGURE9.2.
1. Removethetwobackheightadjustmentscrewsandlocknutsthatsecurethetwoback
canestothewheelchairframe.
2. Repositionthebackcanestooneoffiveheightadjustmentholes.
NOTE:Bothbackcanesshouldbeadjustedtothesameadjustmenthole.
3. Reinstallthetwobackheightadjustmentscrewsandlocknutsthatsecuretheback
canestothewheelchairframe.
FIGURE 9.2 Adjusting the Back Height
Adjusting the Back Angle
NOTE:Forthisprocedure,refertoFIGURE9.3onpage58.
NOTE:Thisprocedureappliestoadjustableanglebacksonly.
NOTE:Thebackadjuststofourpositionsinfivedegreeincrementsfrom0°to15°.
1. Removethetwobackangleadjustmentscrewsandlocknuts.
2. Repositionthebacktothedesiredangle.
3. Ensuretheupperbackanglemountingholeisalignedwithoneofthefourupper
angleadjustmentholes.
4. Installoneofthebackangleadjustmentscrewsthroughtheupperbackangle
mountingholeandthedesiredupperangleadjustmenthole.
Wheelchair
Frame
Back Height
Adjustment
Holes*
1
2
3
4
5
Back Height
Adjustment
Screw
Back
Cane
Back Upholstery
*NOTE:Holesnumberedfor
referenceonly.(Thereareno
numbersonthewheelchair
frameorbackcanes.)
Locknut
Back Height
Adjustment
Screw
Locknut
