Invacare ProSPIN X4 - Adjusting Wheelbase Length

SECTION 11—WHEELS
Part No 1125104 75 ProSPIN™ X4™
3. Movetheaxlebushinginorouttothe
desiredposition.
4. Torquethejamnutsto40‐45ft‐lbsto
securetheaxlebushingtotheaxle
mountingplate.
5. Reinstalltherearwheelontothe
wheelchair.Referto
Removing/InstallingRearWheelson
page 67.
6. RepeatSTEPS1‐5fortheoppositeside
ofthewheelchair.
FIGURE 11.8 Adjusting Wheelbase Width
Adjusting Wheelbase Length
NOTE:Forthisprocedure,refertoFIGURE11.9onpage76.
NOTE:Thewheelbasecanbeadjustedin¼inchincrements.
NOTE:Lengtheningthewheelbasewillincreasestabilityandmaintainstandardmaneuverability
ofthewheelchair.
NOTE:Shorteningthewheelbasewilldecreasethestability,increasemaneuverabilityand
distributeadditionalweightontotherearwheels.
1. Removetherearwheelfromthewheelchair.RefertoRemoving/InstallingRear
Wheelsonpage 67.
2. Removethetwotopmountingscrews,washersandlocknutssecuringtheaxle
mountingplatetothewheelchairframe.
3. Removethetwobottommountingscrewswasherscamberspacers(ifpresent)and
locknutssecuringtheaxlemountingplatetothewheelchairframe.
NOTE:Framemountingpositionsarespaced½inchapart.
4. Align
theaxlemountingplatemountingholeswiththedesiredframemountingholes.
5. Usingthetwotopmountingscrews,washersandlocknuts,looselysecuretheaxle
mountingplatetothewheelchairframe.
6. Usingthetwobottommountingscrewswasherscamberspacers(ifpresent)and
locknuts,looselysecuretheaxlemountingplatetothe
wheelchairframe.
NOTE:Theaxlemountingplatemountingholesareoblongandcanbeusedtofinetunethe
wheelbasemeasurementby¼inch.
7. Positiontheaxlemountingplatetowardsthefrontorrearofwheelchairtoobtainthe
desiredwheelbasemeasurement.
8. Securelytightenmountinghardware.
Axle Plate
Large
Washer
Jam
Nut
Jam
Nut
Axle
Bushing
Large
Washer
