SECTION 7—FRONT RIGGINGS
ProSPIN™ X4™ 46 Part No 1125104
Replacing Heel Loop
NOTE:Forthisprocedure,refertoFIGURE7.8.
1. Removethemountingboltandcovedwasherthatsecurethefootresttubetothe
footrestsupport.
2. Removethelowerfootrestassembly.
3. Removethemountingscrew,spacer
andlocknutthatsecuretheheelloopto
thefootplate.
4. Slideheelloopoverfootresttube.
NOTE:Whensecuringtheheellooptothe
footrestassembly,tightenthemountingscrew
andlocknutuntilthespacerissecure.
5. Usingthemountingscrew,spacerand
locknut,securetheheellooptothe
footplate.
6. Usingthemountingboltandcoved
washer,securethefootresttubetothe
footrestsupport.
FIGURE 7.8 Replacing Heel Loop
Installing Impact Guards/Calf Strap
NOTE:Forthisprocedure,refertoFIGURE7.9.
1. Removeimpactguard/calfstrapfrom
packagedcontainerifnotalready
securedtothefrontrigging.
2. Securetheimpactguardsaroundthe
frontrigging.
3. Securetheoptionalcalfstraparound
thefootrestframe(withtheimpact
guardsattached).
FIGURE 7.9 Installing Impact Guards/Calf
Strap
Mounting
Bolt
Mounting Screw
Spacer
Locknut
Heel
Loop
Footplate
Footrest Support
Footrest
Tube
Coved
Washer
Calf
Strap
Impact
Guard
Front
Rigging
