Invacare ProSPIN X4 - Installing Removing Seat Positioning Strap

SECTION 10—SEAT
ProSPIN™ X4™ 64 Part No 1125104
Installing/Removing Seat Positioning Strap
NOTE:Forthisprocedure,refertoFIGURE10.2.
1. Removeseatcushionfromwheelchair,ifnecessary.
2. Removetherearmostmountingscrewsthatsecuretheseatupholsterytotheseatrail.
3. Grasptherearedgeoftheseatupholsteryandliftuptoexposetherearmost
mountingholesinseatrail.
4. Performoneofthefollowing:
•Toinstalltheseatpositioningstrap,proceedtoSTEP5.
•Removetheexistingseatpositioningstrapfromthewheelchair.
5. Securethetwohalvesofthenewseatpositioningstraptogether.
6. Positiononeendofthenewseatpositioningstrapbetweentheseatupholsteryandthe
seatrail.
7. Alignthemountingholesontheseatupholstery,seatrail,andoneendofthenewseat
positioningstrap.
8. Securethenewseatpositioningstrapsandseatupholsterytotheseatrailwiththetwo
mountingscrews.Torqueto25‐30in‐lbs.
NOTE:Ensurestrapisorientedproperlyandnottwistedwheninstalling.
9. RepeatSTEPS6‐8foroppositesideoftheseatpositioningstrap.
10. Reinstallseatcushionontowheelchair,ifnecessary.
FIGURE 10.2 Installing/Removing Seat Positioning Strap
Rear Most
Mounting Screws
Rear Edge of Seat
Upholstery
Seat
Rail
Seat Positioning Strap Half
Seat Positioning Strap Half
NOTE:OnlyHookandLoopstyle
seatpositioningstrapshown.Auto
styleseatpositioningstrapattaches
thesameway.
