SECTION 7—FRONT RIGGINGS
ProSPIN™ X4™ 40 Part No 1125104
SECTION 7—FRONT RIGGINGS
 WARNING
After ANY adjustments, repair or service and before use, make sure all attaching
hardware is tightened securely - otherwise injury or damage may occur.
NOTE:ForoperationproceduresrefertoInstalling/RemovingtheFrontRiggingsonpage 29.
Adjusting Footrest Height
NOTE:Forthisprocedure,refertoFIGURE7.1.
1. Removeimpactguardsand/orcalfstrap,ifsoequipped.
2. Removethemountingboltandcovedwasher .
3. Positionthefootrestassemblytothedesiredheight.
4. Alignthedesiredfootresttubemountingholewiththefootrestsupportmounting
hole.
5. Usingthecovedwasherandmountingbolt,securethefootresttubetothefootrest
support.Securelytighten.
6. Ifnecessary,repeatSTEPS2‐4toadjustremainingfootrest.
7. Reinstalltheimpactguardsand/orcalfstrap,ifsoequipped.
FIGURE 7.1 Adjusting Footrest Height
Mounting Bolt
Coved Washer
Footrest Assembly
Footrest Support
Footrest Tube
