SECTION 11—WHEELS
ProSPIN™ X4™ 68 Part No 1125104
Permanent Axles
1. Removethemountingboltandlocknutthatsecuretherearwheeltotheaxlebushing.
2. Removetherearwheel.
3. RepeatSTEP1‐2fortheoppositerearwheel.
4. Toreinstalltherearwheelonto theaxlebushing,reverseSTEPS1‐3.
FIGURE 11.1 Removing/Installing Rear Wheels
Adjusting Quick-Release Axles
NOTE:Forthisprocedure,refertoFIGURE11.2.
1. Removerearwheelandquick/quad‐releaseaxlefromthewheelchair.Referto
Removing/InstallingRearWheelsonpage 67.
2. Depressdetentpininthequick‐releaseaxleandslideaxlethroughthewheelhub.
3. Releasedetentpinensuringthatthelockingpinsarefullyreleased.
4. Increaseordecreaseendplaybyadjustingthelocknutontheendofthequick‐release
axle.
 WARNING
Make sure the detent pin and locking
pins of the quick-release axle are fully
released before operating wheelchair.
Keep locking pins clean.
5. Reinstallrearwheelontothe
wheelchair.Referto
Removing/InstallingRearWheelson
page 67.
FIGURE 11.2 Adjusting Quick-Release
Axles
Permanent Axle
Quick-Release Axle
Axle Bushing
Mounting Bolt
Locknut
Axle Bushing
Quick Release Axle
Rear Wheel
Rear
Wheel
Axle Mounting Plate
Locking
Pins
Wheel Hub
Quick-Release Axle
Detent
Pin
Locknut
