SECTION 4—WHEELCHAIR OPERATION
Part No 1125104 29 ProSPIN™ X4™
Installing/Removing the Front Riggings
NOTE:Forthisprocedure,refertoFIGURE4.4.
NOTE:Formaintenanceand/oradjustmentproceduresrefertoFrontRiggingsonpage 40.
NOTE:Thisprocedureappliestotheswingawayfootrestsandtheelevatinglegrests.
Installing
1. Turnthefrontriggingassemblytotheside(openfrontriggingisperpendicularto
wheelchair).
2. Insertfootrestmountingpinintomountingtube.
3. Pushthefrontriggingassemblytowardstheinsideofthewheelchairuntilitlocksinto
place.
NOTE:Thefootplatewillbeontheinsideofthewheelchairwhenlockedin
place.
4. Repeatthisprocedurefortheotherfrontriggingassembly.
Removing
1. Pushthefrontriggingreleaseleverinward.
2. Rotateswingawayfrontriggingassemblyoutwardorinward.
3. Lifttheswingawayfrontriggingassemblyoffofthemountingtube.
FIGURE 4.4 Installing/Removing the Front Riggings
Mounting Pin
Front Rigging Assembly
Mounting Tube
Front Rigging
Release Lever
Footplate
NOTE:Swingaway
footrestsshown.
Outward
Inward (Inside of Wheelchair)
Wheelchair
Frame
