SECTION 15—TRANSPORT READY OPTION
Part No 1125104 99 ProSPIN™ X4™
Securing the Occupant
Wheelchair-Anchored Belts
 WARNING
The pelvic belt that is provided by Invacare has been tested for use in a motor vehi-
cle on this wheelchair only. DO NOT replace the pelvic belt with a different style
pelvic belt.
NOTE:Forthisprocedure,refertoFIGURE15.2.
Thewheelchairhasbeenprovidedwithapelvicbeltwhichmeetstherequirementsof
ANSI/RESNAWC/19.
ThepelvicbeltprovidedbyInvacarehasbeendesignedtoaccommodateuseoneither
sideofthevehicle.Ifnecessary,followtheinstructionsbelowtoreversetheorientationof
thepelvicbelttoaccommodatethevehicle‐anchoreduppertorsobelt.
1. Installthepelvicbeltpin(DetailʺAʺofFIGURE15.2)intoslotinthepelvicbelt
bracket.Pullupwardsuntilitsnapsintoplace.
NOTE:Notethepositionofthemaleendofthebeltwheninstallingthepelvicbeltontothepelvic
beltbrackets.Themaleendofthepelvicbelt(DetailʺAʺofFIGURE15.2)hasapinwhichisused
tosecurethevehicle‐anchoreduppertorsobelt.
2. RepeatSTEP1fortheoppositepelvicbeltbracket.
3. Installthevehicle‐anchoreduppertorsobeltontothepinonthemaleendofthepelvic
belt.
FIGURE 15.2 Wheelchair-Anchored Belts
Tie-Down Bracket
Pelvic Belt Bracket
Slot
Pin
Pin
Male End
Pin (Used to secure the vehicle-
anchored upper torso belt)
Pelvic End
DETAIL “A”
