Invacare ProSPIN X4 - Adjusting Swingaway Padded Armrest Height

SECTION 8—ARMS
Part No 1125104 55 ProSPIN™ X4™
Adjusting Swingaway Padded Armrest Height
NOTE:Forthisprocedure,refertoFIGURE8.10.
1. Removethehalfarmfromthearmsocket.
2. Removethemountingbolt,twowashersandlocknutmountedinthearmsocketthat
determinetheswingawaypaddedarmrestheight.
3. Repositionmountingboltandonewashertooneofthreepositionsinthearmsocket
dependingonthedesiredheight.
4. Retightenthemountingboltandwashertothearmsocketwiththeremainingwasher
andlocknut.
5. Reinstallthehalfarmintothearmsocket.
6. RepeatSTEPS1‐5fortheoppositeside,ifnecessary.
FIGURE 8.10 Adjusting Swingaway Padded Armrest Height
Swingaway Padded Armrest
Arm Socket
Mounting Bolt
Locknut
Washer
Three Mounting Positions
Washer
