SECTION 7—FRONT RIGGINGS
ProSPIN™ X4™ 44 Part No 1125104
Adjusting Footplate Height
NOTE:Forthisprocedure,referto
FIGURE7.5.
1. Removethetwomountingscrews,
washers,andcovedwashersthat
securethefootresttothefootresttubes.
2. Movethefootplatetooneofthenine
heightadjustmentholes.
3. Installthetwomountingscrews,
washers,andcovedwasherstosecure
thefootplatetothefootresttubes.
FIGURE 7.5 Adjusting Footplate Height
Using the Flip-Up Footrest
NOTE:Forthisprocedure,referto
FIGURE7.6.
NOTE:Thisprocedureisforfixedfrontframes
only.
NOTE:Followthestepsbelowtoenterthe
wheelchair.ReverseSTEPS1‐3toexitthe
wheelchair.
1. Rotatethelatchuntiltheengagement
knobisfree.
2. Pullouttheengagementknobfromthe
extensiontube.
3. Rotatetheflip‐upfootrestoutoftheway.
FIGURE 7.6 Using the Flip-Up Footrest
Footrest
Footrest Tube
Mounting
Screw
Washer
Coved
Washer
Engagement Knob
Flip-Up
Footrest
Latch
Extension
Tube
