Invacare ProSPIN X4 - Adjusting The T-Arms

SECTION 8—ARMS
ProSPIN™ X4™ 50 Part No 1125104
Adjusting The T-Arms
Adjusting T-Arm Height
NOTE:Forthisprocedure,refertoFIGURE8.4.
1. UnlocktheT‐armbyflippingtheT‐armreleaselevertowardstheinsideofthe
wheelchair.
NOTE:Ifnecessary,pulltheT‐armrelease
leveroutandrotate180°soitcanbeflipped
towardstheoutsideofthewheelchair.
2. SlidetheT‐armtooneofthefollowing
heightpositions:
•LowHeightT‐arms‐Nine
positions.
•HighHeightT‐arms‐Seven
positions.
NOTE:IftheinsideT‐armpostdoesnotslide
upanddownintheoutsideT‐armpostas
desired,performoneofthefollowing:
•Tighten‐Tighteningthesetscrewson
theoutsideT‐armpostwillmakeit
moredifficulttomovetheinsideT‐arm
postupanddown.
• Loosen‐Looseningthesetscrewsonthe
outsideT‐armpostwillmakeiteasierto
movetheinsideT‐armpostupand
down.
3. LocktheT‐armbyflippingthe
T‐arm
releaselevertowardsthefrontofthe
wheelchair.
FIGURE 8.4 Adjusting T-Arm Height
Set Screws
T-Arm Release Lever -
Unlocked Position
Outside T- Arm Post
T-Arm Release Lever -
Locked Position
Inside T-Arm
Post
T-Arm
