SECTION 9—BACK
Part No 1125104 59 ProSPIN™ X4™
FIGURE 9.4 Installing/Removing the Chest Positioning Strap
Removing/Installing the Standard Back Upholstery
NOTE:Forthisprocedure,refertoFIGURE9.5onpage60.
Removing
1. Cutthetie‐wrapsthatsecurethebottomoftheexistingbackupholsterytothe
wheelchairframe.
2. Removethetwomountingscrewsandwashersthatsecuretheexistingback
upholsterytothebackcanes.
3. Removethebackheightadjustmentscrewandlocknutthatsecureonebackcaneto
thewheelchairframe.
NOTE:Itmaybenecessarytopullthebackupholsteryuptorevealthebackheightadjustment
screwsecuringthebackcanetothewheelchairframe.
NOTE:Itisnecessarytoremoveonlyonebackcanetoreplacethebackupholstery.
4. Pulltheloosebackcaneoutoftheexistingbackupholstery.
5. Pull
theexistingbackupholsteryupandoverthemountedbackcane.
Chest Positioning
Strap Half
Chest Positioning Strap Half
Washer
Back Cane
Mounting Screws
Back Upholstery
Washer
SECURE THESE ENDS TOGETHER
NOTE:Onlyhookandloopstyle
chestpositioningstrapshown.
Autostylechestpositioningstrap
attachesthesameway.
Mounting Screws
