SECTION 9—BACK
ProSPIN™ X4™ 56 Part No 1125104
SECTION 9—BACK
 WARNING
After ANY adjustments, repair or service and before use, make sure all attaching
hardware is tightened securely - otherwise injury or damage may occur.
Removing/Installing the Back Canes
NOTE:Forthisprocedure,refertoFIGURE9.1.
Removing the Back Cane
NOTE:Reversethisproceduretoinstallthebackcanes.
1. Removethebackupholsteryorback/
seatingsystemfromthewheelchair.
RefertoRemoving/Installingthe
StandardBackUpholsteryonpage 59,
AdjustableBackUpholsteryonpage 60
ortheowner’smanualshippedwith
theback/seatingsystem.
2. Removethearmsfromthewheelchair.
RefertoArmsonpage 47.
3. Removethetwomountingscrewsand
locknutsthatsecurethebottomofthe
backcanetothebackcanemounting
bracket.
4. Liftupandremovethebackcanefrom
thewheelchair.
5. Ifnecessary,repeatSTEPS3‐4to
removetheremainingbackcane.
6. ReverseSTEPS1‐5toinstallthenew
backcane.
FIGURE 9.1 Removing/Installing the Back
Canes
Mounting
Screws
Back Cane
Mounting Bracket
Back Cane
Locknuts
