Table 3: Assignable functions (continued)
Function Description
6 Dials 6.
7 Dials 7.
8 Dials 8.
9 Dials 9.
# Dials #.
* Dials * .
Voice Monitoring Monitor voice activity on a private line speaker call. Notify the end user
when no talkback voice is detected on the line within a specified time
interval once voice is detected from the far end counterparty. Button is
configured by an administrator from the UMS only.
4.9.1 Configure function buttons
Configure function buttons to access turret functions.
You must have user programming privileges set in your trader profile to assign function buttons.
1. If the Favorites application is not already displayed, tap Favorites in the Navbar.
2. Tap an unassigned or empty button.
A contextual menu is displayed with the button types.
3. Tap FUNCTION.
The Add Button: Function Button Options dialog is displayed.
4. Select the desired button type.
5. Use the predefined button descriptor or optionally delete that description and enter your own using
the soft keyboard.
Button descriptions that exceed the display length for a button are truncated and the hidden characters
are represented by an ellipsis (...). Truncation always occurs on the right. For example, Do Not
Ring is displayed as Do Not Ri.... The number of characters displayed is based on the font
magnification setting.
6. Tap Save.
The button is created.
4.10 Batch settings mode
In the Favorites Batch settings mode (also called Batch edit mode), you can edit the settings of all line
buttons in the button sheet. Other types of buttons are inactive in this mode, and cannot be edited. While
in Batch settings mode, real time button status is not displayed.
The following settings can be edited in Batch settings mode:
•
Priority
•
Ring tone override
•
Ring settings
•
Fixed
4.10: Batch settings mode 57
IPC Proprietary Unigy 4.3
IQ/MAX TOUCH Turret User Guide
