Juniper EX2200 User Manual

Table 29: EX2200 Switch Mounting Methods (continued)
CommentsSwitch ModelMounting Method
•
On a wall by using screws or separately orderable wall-mount
kit
•
On a wall by using screws
•
EX2200
•
EX2200-C
Wall mount
On or under a surface made of ferrous material using the separately
orderable magnet sheet
EX2200-CMagnet mount
WARNING:
When mounting an EX2200 switch chassis in a vertical position, orient the
front panel of the chassis downward to ensure proper airflow and meet
safety requirements in the event of a fire.
•
•
When wall mounting EX2200-24P and EX2200-48P models, install the
wall-mount baffle above the units to reduce the risk of objects or
substances falling into the air exhaust or power supply, which could cause
a fire.
The holes in the mounting brackets are placed at 1 U (1.75 in. or 4.45 cm) apart so that
the switch can be mounted in any rack or cabinet that provides holes spaced at that
distance.
See the Related Documentation for detailed descriptions of the various rack or cabinet
mounting options.
Related
Documentation
Mounting an EX2200 Switch on Two Posts of a Rack or Cabinet on page 95•
• Mounting an EX2200 Switch on Four Posts of a Rack or Cabinet on page 98
• Mounting an EX2200 Switch in a Recessed Position in a Rack or Cabinet on page 102
• Mounting an EX2200 Switch on a Desk or Other Level Surface on page 89
• Mounting an EX2200 Switch on a Wall on page 102
• Mounting an EX2200 Switch On or Under a Desk Using Screws on page 92
• Mounting an EX2200 Switch Using the Magnet Mount on page 109
• Connecting Earth Ground to an EX Series Switch on page 117
Mounting an EX2200 Switch on a Desk or Other Level Surface
You can mount an EX2200 switch on a desk or other level surface by using the four rubber
feet that are shipped with the switch. The rubber feet stabilize the chassis.
Before mounting the switch on a desk or other level surface:
89Copyright © 2015, Juniper Networks, Inc.
Chapter 8: Installing the Switch

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
