Table 20: Site Preparation Checklist (continued)
DatePerformed byFor More InformationItem or Task
“Rack Requirements for EX2200
Switches” on page 71
“Cabinet Requirements for EX2200
Switches” on page 72
Verify that your rack or cabinet meets the
minimum requirements for the installation of
the switch.
“Clearance Requirements for Airflow
and Hardware Maintenance for
EX2200 Switches” on page 74
Plan rack or cabinet location, including required
space clearances.
Secure the rack or cabinet to the floor and
building structure.
Wall
“Requirements for Mounting an
EX2200 Switch on a Desktop or Wall
on page 73
Verify that the wall meets the minimum
requirements for the installation of the switch.
“Clearance Requirements for Airflow
and Hardware Maintenance for
EX2200 Switches” on page 74
Verify that there is appropriate clearance in your
selected location.
Cables
Acquire cables and connectors:
Determine the number of cables needed
based on your planned configuration.
Review the maximum distance allowed for
each cable. Choose the lengthof cable based
on the distance between the hardware
components being connected.
Plan the cable routing and management.
Related
Documentation
General Safety Guidelines and Warnings on page 169
General Site Guidelines on page 62
Installing and Connecting an EX2200 Switch on page 85
Mounting an EX2200 Switch on page 88
General Site Guidelines
This topic applies to hardware devices in the EX Series product family, which includes
EX Series switches, the EX Series Redundant Power System (RPS), and the XRE200
External Routing Engine.
This topic also applies to hardware devices in the QFX Series and to OCX1100 switches.
Copyright © 2015, Juniper Networks, Inc.62
Complete Hardware Guide for EX2200 Ethernet Switches
