Juniper EX2200 User Manual

Table 10: Status LED on the Management Port on EX2200 Switches
State and DescriptionColorLED
Indicates the speed. The speed indicators are:
•
One blink per second—10 Mbps
•
Two blinks per second—100 Mbps
GreenStatus
Related
Documentation
Connecting a Switch to a Network for Out-of-Band Management on page 127•
Power Supply in EX2200 Switches
The power supply in EX2200 switches is built in along the rear panel of the chassis, with
an AC power cord inlet or DC power terminals on the rear panel to connect power to the
switch.
Table 11 on page 18 lists the power consumed by each EX2200 switch model. The
maximum power available on a PoE port is 30 W for switches running Junos OS Release
10.3 or later and 15.4 W for switches running Junos OS Release 10.2 or earlier.
Table 11: Power Consumed by EX2200 Switches
Maximum PoE Power
Available
Maximum Power
Consumed by the Switch
Number of PoE-Enabled
PortsModel Number
–30 W–EX2200-C-12T
100 W30 W (when no PoE power is
drawn)
12EX2200-C-12P
–50 W–EX2200-24T
405 W60 W (when no PoE power is
drawn)
24EX2200-24P
–50 W–EX2200-24T-DC
–76 W–EX2200-48T
405 W91 W (when no PoE power is
drawn)
48EX2200-48P
Related
Documentation
AC Power Cord Specifications for EX2200 Switches on page 80•
• EX2200 Switches Hardware Overview on page 3
• Power Specifications for EX2200 Switches on page 79
• Connecting AC Power to an EX2200 Switch on page 123
• Connecting DC Power to an EX2200 Switch on page 125
Copyright © 2015, Juniper Networks, Inc.18
Complete Hardware Guide for EX2200 Ethernet Switches

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
