CHAPTER 5
Mounting and Clearance Requirements
•
Rack Requirements for EX2200 Switches on page 71
•
Cabinet Requirements for EX2200 Switches on page 72
•
Requirements for Mounting an EX2200 Switch on a Desktop or Wall on page 73
•
Clearance Requirements for Airflow and Hardware Maintenance for EX2200
Switches on page 74
Rack Requirements for EX2200 Switches
You can mount the EX2200 switches on two-post racks or four-post racks.
Rack requirements consist of:
•
Rack type
•
Mounting bracket hole spacing
•
Rack size and strength
•
Rack connection to the building structure
Table 23 on page 71 provides the rack requirements and specifications for the switch.
Table 23: Rack Requirements and Specifications for the Switch
GuidelinesRack Requirement
Use a two-post rack or a four-post rack. You can mount the switch on any two-post or four-post
rack that provides bracket holes or hole patterns spaced at 1 U (1.75 in./4.45 cm) increments and
that meets the size and strength requirements to support the weight.
A U is the standard rack unit defined in Cabinets, Racks, Panels, and Associated Equipment (document
number EIA-310–D) published by the Electronics Industry Association
(http://www.ecianow.org/standards-practices/standards/) .
The rack must meet the strength requirements to support the weight of the chassis.
Rack type
The holes in the mounting brackets are spaced at 1 U (1.75 in. or 4.45 cm), so that the switch can be
mounted in any rack that provides holes spaced at that distance.
Mounting bracket hole
spacing
71Copyright © 2015, Juniper Networks, Inc.
