Table 14 on page 24 provides the pinout information for the RJ-45 console connector.
An RJ-45 cable and an RJ-45 to DB-9 serial port adapter are supplied with the switch.
NOTE: If your laptop or PC does not have a DB-9 male connector pin and you
want to connect your laptop or PC directly to an EX Series switch, use a
combination of the RJ-45 to DB-9 female adapter supplied with the switch
and a USB to DB-9 male adapter. You must provide the USB to DB-9 male
adapter.
Table 14: EX Series Switches Console Port Connector Pinout Information
DescriptionSignalPin
Request to sendRTS Output1
Data terminal readyDTR Output2
Transmit dataTxD Output3
Signal groundSignal Ground4
Signal groundSignal Ground5
Receive dataRxD Input6
Data carrier detectCD Input7
Clear to sendCTS Input8
Related
Documentation
EX2200 Switches Hardware Overview on page 3
Rear Panel of an EX3200 Switch
Rear Panel of an EX3300 Switch
Rear Panel of an EX4200 Switch
EX4300 Switches Hardware Overview
Front Panel of an EX4500 Switch
EX4550 Switches Hardware Overview
Management Panel of an EX4600 Switch
Switch Fabric and Routing Engine (SRE) Module in an EX6200 Switch
Switch Fabric and Routing Engine (SRE) Module in an EX8208 Switch
Routing Engine (RE) Module in an EX8216 Switch
Connecting a Switch to a Management Console on page 129
Configuring the Console Port Type (CLI Procedure)
Copyright © 2015, Juniper Networks, Inc.24
