Juniper EX2200 - Table 19: Optical Interface Support and Copper Interface Support for SFP

Table 19: Optical interface Support and Copper Interface Support for SFP Transceivers in
EX2200-C Switches
ValueSpecificationEthernet Standard
EX-SFP-1GE-SXModel number1000BASE-SX
1000 MbpsRate
LCConnector type
DualFiber count
850 nmTransmitter wavelength
–9.5 dBmMinimum launch power
–3 dBmMaximum launch power
–21 dBmMinimum receiver sensitivity
0 dBmMaximum input power
MMFFiber type
50/125 µm50/125 µm62.5/125 µm62.5/125 µmCore/Cladding size
OM2–OM1FDDIFiber grade
500 MHz/km400 MHz/km200 MHz/km160 MHz/kmModal bandwidth
550 m
(1804 ft)
500 m
(1640 ft)
275 m
(902 ft)
220 m
(722 ft)
Distance
Junos OS for EX Series switches, Release 11.3 or laterSoftware required
YesSupport for Virtual Chassis
configuration
