Juniper EX2200 User Manual

Figure 40: Securing the EX2200-C Switch Using Security Slots
g021160
Security slot
Security cable
Related
Documentation
Connecting AC Power to an EX2200 Switch on page 123•
• Connecting DC Power to an EX2200 Switch on page 125
• Connecting and Configuring an EX Series Switch (CLI Procedure) on page 139
• Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 142
• Wall-Mounting Warnings for EX2200 Switches on page 189
Mounting an EX2200 Switch Using the Magnet Mount
This topic applies only to the EX2200-C switch, the compact, fanless model.
You can mount an EX2200-C switch on or under a surface made of ferrous material using
the separately orderable magnet sheet.
WARNING: When mounting anEX2200-C switchchassisina verticalposition,
orient the front panel of the chassis downward to ensure proper airflow and
meet safety requirements in the event of a fire.
NOTE: Do not block the vents on the top of the EX2200-C switches. Doing
this can lead to overheating of the switch chassis.
Before mounting the switch using magnet mount:
•
Ensure that no rubber feet are installed on the bottom of the switch.
•
Verify that the site meets the requirements described in “Site Preparation Checklist
for EX2200 Switches” on page 61.
109Copyright © 2015, Juniper Networks, Inc.
Chapter 8: Installing the Switch

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
