Connecting AC Power to an EX2200 Switch
The power supply in an EX2200 switch is located on the rear panel.
Ensure that you have the following parts and tools available:
•
A power cord appropriate for your geographical location
•
A power cord retainer clip
Ensure that you have connected the switch chassis to earth ground.
CAUTION: To meet safety and electromagnetic interference (EMI)
requirements and toensureproperoperation, you must connect the switches
to earth ground before you connect them to power. For installations that
require a separate grounding conductor to the chassis, use the protective
earthing terminal on the switch chassis to connect to the earth ground. For
instructions on connecting earth ground, see “Connecting Earth Ground to
an EX SeriesSwitch”on page117. An EX2200 switchgets additionalgrounding
when you plug the power supply in the switch into a grounded AC power
outlet by using the AC power cord appropriate for your geographical location
(see “AC Power Cord Specifications for EX2200 Switches” on page 80).
123Copyright © 2015, Juniper Networks, Inc.
Chapter 10: Connecting the Switch

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
