Table 4: Physical Specifications of the EX2200 Switch Chassis
EX2200-C ValueEX2200 ValueDescription
1.75 in. (4.4 cm)1.75 in. (4.45 cm)Chassis height
10.6 in. (26.92 cm)
19 in. (48.26 cm) with mounting brackets
17.5 in. (44.5 cm)
19 in. (48.2 cm) with mounting brackets
attached
Chassis width
EX2200-C-12T: 9.0 in. (22.8 cm)
EX2200-C-12P: 9.4 in. (23.8 cm)
10.5 in. (26.7 cm)Chassis depth
EX2200-C-12T: 4.6 lb (2.1 kg)
EX2200-C-12P: 6.4 lb (2.9 kg)
EX2200-24T: 6 lb (2.7 kg)
EX2200-24P: 8 lb (3.6 kg)
EX2200-24T-DC: 6 lb (2.7 kg)
EX2200-48T: 8 lb (3.6 kg)
EX2200-48P: 10 lb (4.5 kg)
Weight
Related
Documentation
Rack Requirements for EX2200 Switches on page 71
Cabinet Requirements for EX2200 Switches on page 72
Mounting an EX2200 Switch on page 88
Installing and Connecting an EX2200 Switch on page 85
EX2200 Switch Hardware and CLI Terminology Mapping
This topic describes the hardware terms used in EX2200 switch documentation and the
corresponding terms used in the Junos OS command line interface (CLI). See
Table 5 on page 10.
Table 5: CLI Equivalents of Terms Used in Documentation for EX2200 Switches
Additional
Information
Item in
Documentation
Value (as displayed
in the CLI)
Description (as
displayed in the CLI)
Hardware Item (as
displayed in the CLI)
“Chassis Physical
Specifications for
EX2200 Switches” on
page 9
Switch chassisOne of the following:
EX2200-C-12T-2G
EX2200-C-12P-2G
EX2200-24T-4G
EX2200-24P-4G
EX2200-24T-4G-DC
EX2200-48T-4G
EX2200-48P-4G
Chassis
Copyright © 2015, Juniper Networks, Inc.10
Complete Hardware Guide for EX2200 Ethernet Switches
