Page #88 background imageLoading...
Page #88 background image
Table 23: Rack Requirements and Specifications for the Switch (continued)
GuidelinesRack Requirement
Ensure that the rack complies with the standard defined for 19-in. rack as defined in Cabinets,
Racks, Panels, and Associated Equipment (document number EIA-310–D) published by the
Electronics Industry Association (http://www.ecianow.org/standards-practices/standards/)
.
Ensure that the rack rails are spaced widely enough to accommodate the switch chassis' external
dimensions . The outer edges of the front-mounting brackets extend the width of the chassis to
19 in. (48.2 cm).
The rack must be strong enough to support the weight of the switch.
Ensure that the spacing of rails and adjacent racks allows for the proper clearance around the
switch and rack.
Rack size and strength
Secure the rack to the building structure.
If earthquakes are a possibility in your geographical area, secure the rack to the floor.
Secure the rack to the ceiling brackets as well as wall or floor brackets for maximum stability.
Rack connection to
building structure
One pair of mounting brackets for mounting the switch on two posts of a rack is supplied
with each switch. For mounting the switch on four posts of a rack or cabinet, you can
order a four-post rack-mount kit separately.
NOTE: Mounting brackets are not supplied with EX2200-C switch; they are
separately orderable.
Related
Documentation
Chassis Physical Specifications for EX2200 Switches on page 9
Clearance Requirements for Airflow and Hardware Maintenance for EX2200 Switches
on page 74
Rack-Mounting and Cabinet-Mounting Warnings on page 184
Mounting an EX2200 Switch on Two Posts of a Rack or Cabinet on page 95
Mounting an EX2200 Switch on Four Posts of a Rack or Cabinet on page 98
Mounting an EX2200 Switch in a Recessed Position in a Rack or Cabinet on page 102
Cabinet Requirements for EX2200 Switches
You can mount the switch in a cabinet that contains a 19-in. rack.
Cabinet requirements consist of:
Cabinet size
Clearance requirements
Cabinet airflow requirements
Table 24 on page 73 provides the cabinet requirements and specifications for the switch.
Copyright © 2015, Juniper Networks, Inc.72
Complete Hardware Guide for EX2200 Ethernet Switches
