Mini-USB Port Specifications for an EX2200 Switch
The EX2200-C switch, the compact, fanless model, has two management console ports:
an RJ-45 port, and a Mini-USB Type-B port.
By default, the RJ-45 port is set as the active console port. It can display all the early boot
and low-level message output and you can access the switch through this port in the
debugger prompt. The Mini-USB Type-B port is the passive console port. You can change
the status of the port to active or passive using the port-type configuration statement.
See Configuring the Console Port Type (CLI Procedure).).
The Mini-USB Type-B console port uses a Mini-B plug (5-pin) connector to connect to
a console management device. The default baud rate for the console port is 9600 baud.
Table 12 on page 22 provides the pinout information of the Mini-USB Type-B console
port.
Table 12: Mini-USB Type-B Console Port Pinout Information for EX2200-C Switches
DescriptionSignalPin
+5 VDCVCC1
Data -D-2
Data +D+3
May be N/C, GND or used as an attached device presence indicatorN/CX
GroundGND4
Copyright © 2015, Juniper Networks, Inc.22
Complete Hardware Guide for EX2200 Ethernet Switches

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
