Chassis Lifting Guidelines for EX2200 Switches
Observe the following guidelines for lifting and moving an EX2200 switch:
•
Before installing the switch, read the guidelines in “Site Preparation Checklist for EX2200
Switches” on page 61 to verify that the intended site meets the specified power,
environmental, and clearance requirements.
•
Before lifting or moving the switch, disconnect all external cables.
Related
Documentation
General Safety Guidelines and Warnings on page 169•
• Installation Instructions Warning on page 181
• Mounting an EX2200 Switch on page 88
Ramp Warning
This topic applies to hardware devices in the EX Series product family, which includes
EX Series switches, the EX Series Redundant Power System (RPS), and the XRE200
External Routing Engine.
This topic also applies to hardware devices in the QFX Series and to OCX1100 switches.
183Copyright © 2015, Juniper Networks, Inc.
Chapter 17: Installation and Maintenance Safety Information

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
