Juniper EX2200 User Manual

•
Place the desk in its permanent location, allowing adequate clearance for airflow and
maintenance, and secure it to the building structure.
•
Read “General Safety Guidelines and Warnings” on page 169, with particular attention
to “Chassis Lifting Guidelines for EX2200 Switches” on page 183.
•
Remove the switch from the shipping carton (see “Unpacking an EX2200 Switch” on
page 86).
Ensure that you have the following parts and tools available:
•
Magnet sheet (separately orderable)
•
Flat surface made of ferrous material
•
1 cable guard and 3 number-8 Phillips truss-head screws (optional and separately
orderable) to secure the cable guard to the switch
•
1 standard cable lock (optional and separately orderable) to secure the switch from
theft by connecting the cable to the security slots on the switch
1. Mount the switch under a ferrous surface using magnet mount:
a. Turn the chassis upside down.
b. Place the magnet sheet on the bottom of the chassis.
NOTE: You can place the magnet sheet only at the bottom of the
switch.
c. Mount the magnet sheet along with the switch under the surface where you want
to mount the switch.
2. Mount the switch vertically on a ferrous surface using magnet mount:
a. Place the magnet sheet at the bottom of the chassis.
NOTE: You can place the magnet sheet only at the bottom of the
switch.
b. Mount the magnet along with the switch on the ferrous surface where you want
to mount the switch orienting the front panel downwards as shown in
Figure 41 on page 111.
Copyright © 2015, Juniper Networks, Inc.110
Complete Hardware Guide for EX2200 Ethernet Switches

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
