are separately orderable. (The remainder of this topic uses “rack” to mean “rack or
cabinet”.)
NOTE: If you need to mount an EX2200 switch except the EX2200-C switch
models in a recessed position on either a two-post rack or a four-post rack,
you can use the 2-in.-recess front mount brackets provided in the separately
orderable four-post rack-mount kit. EX2200-C cannot be mounted in a
recessed position.
NOTE: Do not block the vents on the top of the EX2200-C switches. Doing
this can lead to overheating of the switch chassis.
Before mounting the switch on two posts of a two-post or a four-post rack:
•
Verify that the site meets the requirements described in “Site Preparation Checklist
for EX2200 Switches” on page 61.
•
Place the rack in its permanent location, allowing adequate clearance for airflow and
maintenance, and secure it to the building structure.
•
Read “General Safety Guidelines and Warnings” on page 169, with particular attention
to “Chassis Lifting Guidelines for EX2200 Switches” on page 183.
Ensure that you have the following parts and tools available:
•
Phillips (+) screwdriver, number 2
•
2 mounting brackets and 8 mounting screws (provided with EX2200 switches except
the EX2200-C switch model )
•
Screws to secure the chassis to the rack (not provided)
•
2-in.-recess front brackets from the separately orderable four-post rack-mount kit if
you will mount the switch in a recessed position (not applicableforEX2200-C switches).
NOTE: One person must be available to lift the switch while another secures
the switch to the rack.
CAUTION: If you are mounting multiple units on a rack, mount the heaviest
unit at the bottom of the rack and mount the other units from the bottom of
the rack to the top in decreasing order of the weight of the units.
Copyright © 2015, Juniper Networks, Inc.96
Complete Hardware Guide for EX2200 Ethernet Switches

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
