WARNING: When mounting anEX2200-C switchchassisina verticalposition,
orient the front panel of the chassis downward to ensure proper airflow and
meet safety requirements in the event of a fire.
NOTE: Do not block the vents on the top of the EX2200-C switches. Doing
this can lead to overheating of the switch chassis.
Before mounting the switch on a wall:
•
Verify that the site meets the requirements described in “Site Preparation Checklist
for EX2200 Switches” on page 61.
•
Read “General Safety Guidelines and Warnings” on page 169, with particular attention
to “Chassis Lifting Guidelines for EX2200 Switches” on page 183.
Ensure that you have the following parts and tools available:
•
3 wall mounting screws (M4 x 30mm or 8-32 x 1.25 in. Phillips pan-head machine
screws—not provided)
•
Phillips (+) screwdriver, number 2
•
1 cable guard and 3 number-8 Phillips truss-head screws (optional and separately
orderable) to secure the cable guard to the switch
•
1 standard cable lock (optional and separately orderable) to secure the switch from
theft by connecting the cable to a security slot on the switch
To mount the switch on a wall:
1. Remove the switch from the shipping carton (see “Unpacking an EX2200 Switch” on
page 86).
2. Drill three holes A, B, and C on the wall as shown in Figure 37 on page 107.
