Juniper EX4300 Series User Manual

NOTE: The chassis viewer in the J-Web interface also displays the LCD panel. From the J-Web
interface, you can view real-me status informaon in the LCD panel. See Dashboard for EX
Series Switches .
This topic describes:
LCD Panel Modes
The LCD panel operates in four modes: boot, idle, status, and maintenance.
The rst line of text on the LCD panel displays the slot number, the role of the switch, and hostname in
all the modes.
For a standalone EX4300 switch, by default the slot number is 00, and the role is RE.
In an EX4300 switch that is a member of a Virtual Chassis, the rst line of the LCD panel always
displays:
• The slot number (the member ID of the Virtual Chassis member)
• Role of the switch in the Virtual Chassis (RE for primary, BK for backup, and LC for line card member)
• Hostname
The LCD panel operates in boot mode during switch reboot. In the boot mode, the second line of the
LCD panel displays the key milestones in the switch boot process. The boot mode does not have any
menu opons. Aer the boot process is complete, the LCD panel automacally reverts to the Idle (IDLE)
menu.
In idle mode, the second line of text on the LCD panel displays the mode of the network ports’ Status
LED and the number of chassis alarms. The number of alarms is updated every second.
In status mode, the second line displays:
• Status of the Virtual Chassis port (VCP)
• Status of the power supplies
• Status of the fan modules and the chassis temperature
• Version of Junos OS for EX Series switches loaded on the switch
In maintenance mode, the second line displays one of the following opons, which you can use to
congure and troubleshoot the switch:
• System halt
55

Juniper EX4300 Series Specifications

General

Product Series	EX4300 Series
Power Consumption	Varies by model and configuration
Virtual Chassis Technology	Up to 10 switches
Software	Junos OS
Ports	24-port and 48-port models
10GBASE SFP+ Ports	Up to 8 ports
40GBASE QSFP+ Ports	2
Uplink Ports	Up to 4 ports
Jumbo Frames	Up to 9216 bytes
Operating Temperature	0°C to 45°C
Relative Humidity	5% to 90% noncondensing
Input Voltage	100 to 240V AC
Power Supply	AC or DC
Power Supply Options	AC or DC
Stacking	Yes
Layer 2 Features	Includes VLAN, STP, RSTP, MSTP, LACP
Layer 3 Features	OSPF, BGP
Management	CLI, Web GUI, SNMP
Security Features	DHCP snooping
QoS	8 queues per port, DSCP
Storage Temperature	-40°C to 70°C
