Juniper EX4300 Series

Table 16: Uplink Modules Used in 32-Port EX4300 Switches
Uplink Module Name Model Number Figure
2-port 40-Gigabit
Ethernet QSFP+ uplink
module
EX-UM-2QSFP
Figure 19: 2-Port 40-Gigabit Ethernet QSFP+
Uplink Module
Figure 20: LEDs on the 2-Port 40-Gigabit Ethernet
QSFP+ Uplink Module
1. Status LED of the uplink module
2. Link acvity LED of the uplink module port
3. Status LED of the uplink module port
65
