Juniper EX4300 Series

Table 16: Uplink Modules Used in 32-Port EX4300 Switches (Connued)
Uplink Module Name Model Number Figure
8-port 10-Gigabit
Ethernet SFP+ uplink
module
EX-UM-8X8SFP
Figure 21: 8-Port 10-Gigabit Ethernet SFP+ Uplink
Module
Figure 22: LEDs on the 8-Port 10-Gigabit Ethernet
SFP+ Uplink Module
1. Status LED of the uplink module
2. Link acvity LED of the lower port
3. Link acvity LED of the upper port
4. Status LED the lower port
5. Status LED the upper port
66
