KAESER M27 - Disconnect Electric Consumers; Switching on the Generator; Fig. 35 Generator Cut-In Pictogram

2. Do not exceed the maximum system load caused by electric consumers.
3.
If necessary, reduce the number of connected consumers.
4. Read the technical specification for the generator before connecting voltage-sensitive equip‐
ment.
5. Check that electric consumers and their connecting cables are in perfect condition.
6. Note the labelling of the individual sockets on the generator control cabinet regarding voltages
and amperages.
7. Always connect electric consumers to the sockets one by one.
8. Start electric consumers one by one.
9. Consumers with unfavorable starting characteristics (e.g. high starting current) should be star‐
ted first.
8.5.2 Switching on the generator
Precondition Read and follow the instructions on generator operation.
LOAD mode
A pictogram beneath the generator main switch indicates the correct "cutting-in" of the generator.
Fig. 35 Generator cut-in pictogram
1 Compressed air outlet valve closed.
2 Turn the «generator main switch» to the "l" position.
1. Close the compressed air outlet valves.
2.
Turn the «generator main switch »to the "l" position.
3. Turn the «mode selector switch» to the required mode of operation
4. Switch on the electric consumer.
Further information See chapter 4.6.2.2 for generator controls.
See chapter 4.6.2.1 for generator operating modes.
8.5.3 Disconnect electric consumers
1. Switch off electric consumers one by one.
2. Switch off consumers drawing the highest current last.
3. Remove the plugs from the sockets on the generator control cabinet.
4. Check that the protective covers on the power sockets are correctly closed.
8 Operation
8.5 Generator operation
90
Operator Manual Screw Compressor
M27 No.: 9_9548 05 USE
