Reduced compressed air delivery in generator mode
Voltage [V] 115V, 2-phase
Maximum working gauge
pressure [psig]
100
SIGMA airend 11-G
Reduced delivery [cfm]
Without decrease in pow‐
er output
67
Zero delivery [cfm]
With decrease in power
output
0
Tab. 50 Compressed air delivery in generator mode
Connections
Voltage [V] 115V, 2-phase
Power sockets Number
32 A; 115 V/1~/PE 1
16 A; 115 V/1~/PE 2
Tab. 51 Connection sockets
Circuit breaker
Voltage [V] 115V, 2-phase
Safety cut-out [A] Number
32 1
16 2
Tab. 52 Circuit breaker
Maximum power loading by consumers
Resistive consumers include lamps and heaters, for example.
Electric motors and transformers are inductive consumers.
Nominal rating conditions
■
Ambient temperature: 77°F
■ Max. height above sea level at the place of use: 3000 ft
Single phase power supply
Generator 115V, 2-phase
Rated power [kVA] 6.0
Resistive consumers
[kVA]
6.0
2 Technical Data
2.7 Options
No.: 9_9548 05 USE
Operator Manual Screw Compressor
M27
19
Option gb
