12. Check the correct position of the split pin.
The split pin must be fully inserted so that it is trapped by its bow over the axis of the locking
lever (see 19
).
Check locking position 11
.
■
Split pin 1
properly inserted.
■
Split pin 2
properly inserted.
13.
Tighten the locking lever again after 30 miles.
The serrations in the adjustment joint will not disengage. The serrations are corroded togeth‐
er.
➤
Free the serrations by jerking the towbar horizontally and vertically.
6.4.3 Replacing the ball coupling with a towing eye
The towbar can be fitted with various towing eyes or ball couplings.
Material Protective gloves
New self-locking nuts
Wrench
Hammer
Mounting pin
Precondition The machine is switched off.
The machine is disconnected from the towing vehicle and safely parked.
Reuse of self-locking nuts
The protection against loosening no longer exists.
➤ Use only new, self-locking nuts for the assembly.
➤ Determine which towing device is fitted to the machine.
6.4.3.1 Option rb/rm/rr
Replacing the ball coupling with a towing eye in height-adjustable towing systems
The following alternative tasks must be carried out to change the towing eye or the ball coupling.
6 Installation
6.4 Adjusting the chassis
No.: 9_9548 05 USE
Operator Manual Screw Compressor
M27
63
