4. Lower the support.
5.
Withdraw the security pin from the ball coupling.
6. Pull the coupling handle up and lower the support further.
The ball coupling must be released from the towing device of the towing vehicle.
7. Insert the security pin in the ball coupling fixing opening.
8. Check whether the ball coupling is positioned higher than the towing device of the towing vehi‐
cle.
9. If necessary, lower the jockey wheel further.
10. Slowly remove the towing vehicle from the machine.
12.2.3.5 Option sf
Using the optional anti-theft device
The machine is fitted with a safety chain as theft protection.
The supplied safety chain is stored in a container at the front of the machine.
Fig. 84 Container for safety chain
1 Machine
2 Position of the container for the safety chain
3 Safety chain
1. Open the container cover.
2.
Take the safety chain and pull it out.
3. Wrap the safety chain around a suitable object.
4. Secure the safety chain with the lock.
Result The machine is protected against theft.
12.2.4 Transporting with a crane
Additional precautions for conditions of snow and ice
Considerable snow or ice may build up on the machine under low temperature conditions.
This may adversely effect the machine's center of gravity.
It is possible that the permissible loading on the crane or lifting eye is exceeded.
➤ Perform the following tasks in snow and ice conditions:
■ Remove any snow and ice from the machine before lifting by a crane.
■ Make sure the lifting eye cover plate is freely accessible and can be opened.
12 Decommissioning, Storage and Transport
12.2 Transport
No.: 9_9548 05 USE
Operator Manual Screw Compressor
M27
229
