KAESER M27 - Fig. 21 Replacing the Ball Coupling (Towing Device with Overrun Brake)

Fig. 21 Replacing the ball coupling (towing device with overrun brake)
1 Top part, towing device
2 Ball coupling
3 Self-locking nut
4 Washer
5 Mounting pin
6 Retaining screw, shock absorber
7 Fastening screw
8 Distance bow for ball coupling
9 Towbar tube
10 Distance bush for towing eye
11 Fastening eye of the shock absorber
12 Towing eye
13 New self-locking nut
14 Protective sleeve
6 Installation
6.4 Adjusting the chassis
66
Operator Manual Screw Compressor
M27 No.: 9_9548 05 USE
Option rb/rm/rs
