13
Annex
13.1
Identification
Fig. 86
Identification
1
VIN* (stamped into bodywork)
*Vehicle Identification Number
2
Options label
3
Machine nameplate with serial number
4
Engine nameplate with serial number
13.2
Pipeline and instrument flow diagram (P+I diagram)
13
Annex
13.1
Identification
No.: 9_9548 05 USE
Operator Manual Screw Compressor
M27
233
242
244
