KAESER M27 - Fig. 24 Replacing the Towing Eye with a Ball Coupling

Fig. 24 Replacing the towing eye with a ball coupling
1 Self-locking nut
2 Screw
3 Towing eye
4 Distance bush for towing eye
5 Towbar (mounted rotatable)
6 Towbar tube
7 Ball coupling
8 New self-locking nut
6 Installation
6.4 Adjusting the chassis
No.: 9_9548 05 USE
Operator Manual Screw Compressor
M27
71
Option rg/rp/rr
