13. Make sure that the Satellite is
firmly secured to the installation
surface.
14. Examine the seal of the
charging cable in the rubber
grommet. If necessary, apply
flexible polyurethane sealant to
waterproof the opening.
5.1.13.1. Locking the charging cable inside its support spring
NOTE
Use method A or method B to lock the charging cable in place inside its support
spring.
1. Method A
Make sure that the cable
bushing below the spring holder
is correctly tightened.
Push the charging cable into its
support spring so that it touches
the top side of the support
spring
CHARGING EQUIPMENT FOR ELECTRIC VEHICLES INSTALLATION MANUAL
CONFIDENTIAL – CERTIFIED PARTNERS 82 REV 2.40 EN 04-2024
