Kenwood NX-5200K3 Common Function Reference

DMR Conventional system
In a DMR Conventional system, the channel spacing is fixed at “12.5 (Narrow)”.
P25 Trunking system
The channel spacing can be configured in the Trunked Channel Plan table of a P25 Trunking system within the following
range:
Table 4-4 Channel Spacing (P25 Trunking)
Model Channel Spacing
NX-5200/ NX-5700 2.50 kHz to 127.50 kHz
NX-5300/ NX-5800 5.00 kHz to 125.00 kHz
NX-5400/ NX-5900 6.25 kHz to 125.00 kHz
NXDN Trunking system
In the Frequency Table of an NXDN Trunking system, “12.5 (Narrow)” or “6.25 (Very Narrow)” can be configured for the
channel spacing.
Note
For KPG-D1N, “25.0 (Wide 5k)” cannot be configured for the channel spacing if a receive frequency or transmit frequency
is configured in the following ranges:
VHF: above 149.98750 MHz and less than 174.01250 MHz
UHF: above 420.98750 MHz and less than 470.01250 MHz
Configuration using KPG-D1/ D1N
0
Configuring Channel
Spacing (Personality) in an Analog Conventional system (
Transceiver Settings > Personal
> Personality > Analog Conventional)
0
Configuring Channel Spacing (Channel Edit) in an Analog Conventional system ( Transceiver Settings > Zone/
Channel > Channel Edit > Analog Conventional)
0
Configuring Channel Spacing (Personality) in a P25 Conventional system ( Transceiver Settings > Personal >
Personality > P25 Conventional > General)
0
Configuring Channel Spacing (Channel Edit) in a P25 Conventional system (
Transceiver Settings > Zone/
Channel > Channel Edit > P25 Conventional > General)
0
Configuring Channel
Spacing (Personality) in an NXDN Conventional system (
Transceiver Settings > Personal
> Personality > NXDN Conventional > General)
0
Configuring Channel Spacing (Channel Edit) in an NXDN Conventional system ( Transceiver Settings > Zone/
Channel > Channel Edit > NXDN Conventional > General)
0
Configuring Channel Spacing (Personality) in a DMR Conventional system ( Transceiver
Settings > Personal >
Personality > DMR Conventional > General)
0
Configuring Channel Spacing (Channel Edit) in a DMR Conventional system (
Transceiver Settings > Zone/
Channel > Channel Edit > DMR Conventional > General)
0
Configuring Channel Spacing in a P25 Trunking system (
Transceiver Settings > P25 Network > Trunked
Channel Plan)
0
Configuring Channel
Spacing in an NXDN Trunking system (
Transceiver
Settings > NXDN Network > Frequency
Table > Frequency Edit)
0
Configuring Channel Spacing in an LTR Trunking system (
Transceiver Settings > Personal > Personal Features
> LTR Trunking > General)
4 TRANSMISSION/ RECEPTION
4.3 Channel Spacing
Common FUNC (K, F)/Ver 2.20 81
