If “Control Head 1” is configured in SD Card Selection:
Audio and GPS data can be stored in the microSD card inserted in the SD card slot of Control Head 1 (KCH-20R). Audio
data and GPS data are stored as follows depending on the availability of a microSD card:
Table 16-14 SD Card Selection (Control Head 1)
Type microSD Card Is in Control Head 1 (KCH-20R)
No microSD Card Is in Control Head 1
(KCH-20R)
Audio Data
Stored in the microSD card inserted in Control
Head 1 (KCH-20R).
Stored in the internal memory.
GPS Data
Stored in both the microSD card inserted in
Control Head 1 (KCH-20R) and the internal
memory.
Stored in the internal memory.
If “Control Head 2” is configured in SD Card Selection:
Audio and GPS data can be stored in the microSD card inserted in the SD card slot of Control Head 2 (KCH-20R). Audio
data and GPS data are stored as follows depending on the availability of a microSD card:
Table 16-15 SD Card Selection (Control Head 2)
Type microSD Card Is in Control Head 2 (KCH-20R)
No microSD Card Is in Control Head 2
(KCH-20R)
Audio Data
Stored in the microSD card inserted in Control
Head 2 (KCH-20R).
Stored in the internal memory.
GPS Data
Stored in both the microSD card inserted in
Control Head 2 (KCH-20R) and the internal
memory.
Stored in the internal memory.
The following microSD basic functions work differently between when “RF Deck” is configured and when “Control Head 1”
or “Control Head 2” is configured in SD Card Selection.
1.
Format SD Card
2. Eject SD Card
3. Auto Recording
4. Playback
5. GPS Data Storage
The following describes how each function works.
Formatting a microSD Card (Format SD Card)
For the first use of a microSD card inserted in the RF Deck or KCH-20R in a Multi RF Deck/ Multi Control Head structure,
formatting of a microSD card is required.
A microSD card to be formatted varies according to the configuration in SD Card Selection (RF Deck, Control Head 1,
Control Head 2).
0
RF Deck
By
pressing the Format SD Card key, or by pressing the Menu key to enter Menu Mode and then executing “Format SD
Card Mode”, a microSD card inserted in the Selected RF Deck can be formatted.
0
Control Head 1/ Control Head 2
By pressing the Format SD Card key, or by pressing the Menu key to enter Menu Mode and then executing “Format SD
Card Mode”, a microSD card inserted in Control Head 1/ Control Head 2 (KCH-20R) can be formatted.
16 MULTI RF DECK/ MULTI CONTROL HEAD
16.17 microSD
Common FUNC (K, F)/Ver 2.20 317
