The transceiver has the following indicator and display.
0
LED (TX/ Busy)
0
LCD
0
Selective Call Alert LED
5.1
Busy LED
Busy LED is the function to notify a user visually that the transceiver has received a signal.
The
LED lights green while the transceiver is receiving a signal in an Analog Conventional system, P25 Conventional system,
NXDN Conventional system, and DMR Conventional system.
The LED lights only when the transceiver is on a traffic channel in a P25 Trunking system and NXDN Trunking system. The
Busy LED does not light when the transceiver is on a control channel.
Also, whether the Busy LED will light while the transceiver receives in Emergency Mode can be configured.
Configuration using KPG-D1/ D1N
0
Configuring Busy
LED to be enabled or disabled (
Transceiver Settings > Optional Features > Optional Features
1 > Display > LEDs)
0
Configuring Emergency LED to be enable or disabled ( Transceiver
Settings > Emergency > Emergency Profile)
5.2
Transmit LED
Transmit LED is used to notify a user visually that the transceiver is transmitting.
The Transmit LED lights red while the transceiver is transmitting.
Also, whether the Transmit LED will light while the transceiver transmits in Emergency Mode can be configured.
Configuration using KPG-D1/ D1N
0
Configuring Transmit LED to be enabled or disabled ( Transceiver Settings > Optional Features > Optional
Features 1 > Display > LEDs)
0
Configuring Emergency LED to be enable or disabled ( Transceiver
Settings > Emergency > Emergency Profile)
5 INDICATION AND DISPLAY
5
INDICATION AND DISPLAY
Common FUNC (K, F)/Ver 2.20 88
