Page #111 background imageLoading...
Page #111 background image
0
Configuring Transmit Power in a P25 Trunking system ( Transceiver Settings > Personal > Personal Features
> P25 Trunking > General)
0
Configuring Transmit Power in an NXDN Trunking system ( Transceiver
Settings > Personal > Personal Features
> NXDN Trunking > General)
0
Configuring the Power Threshold in a P25 Trunking system (
Transceiver Settings > Personal > Personal Features
> P25 Trunking > General > RSSI Setting)
0
Configuring the Power Threshold in an NXDN Trunking system ( Transceiver Settings > Personal > Personal
Features > NXDN Trunking > General > RSSI Settings)
0
Configuring Transmit Power (Personality) in an LTR Trunking system (
Transceiver Settings > Personal >
Personality > LTR Trunking)
0
Configuring Transmit Power (Channel
Edit) in an LTR Trunking system (
Transceiver Settings > Zone/Channel
> Channel Edit > LTR Trunking)
4.3
Channel Spacing
Channel Spacing is the channel spacing used by the transceiver to transmit and receive.
Channel spacing is the spacing of frequencies between adjacent channels.
Bandwidths of the channel spacing are as follows:
Table 4-3 Channel Spacing
Channel Spacing Bandwidth
25.0 (Wide)
*1
25.0 (Wide 5k)
*2
25.0 kHz
20.0 (Wide 4k)
*2
20.0 kHz
12.5 (Narrow) 12.5 kHz
6.25 (Very Narrow) 6.25 kHz
*1
Available for the K-type NX-5200/NX-5300/NX-5700/NX-5800 only.
*2
Available for the K-type NX-5400/NX-5900 and all E-type models only.
The available channel spacing varies as follows depending on the communication system:
Analog Conventional system
In an Analog Conventional system, “25.0 (Wide 5k)”, “20.0 (Wide 4k)” or “12.5 (Narrow)” can be configured for the channel
spacing on each channel (Personality).
LTR Trunking system
In an LTR Trunking system, “25.0 (Wide 5k)”, “20.0 (Wide 4k)” or “12.5 (Narrow)” can be configured for the channel spacing
in each system.
P25 Conventional system
In a P25 Conventional system, the channel spacing is fixed at “12.5 (Narrow)”.
NXDN Conventional system
In an NXDN Conventional system, “12.5 (Narrow)” or “6.25 (Very Narrow)” can be configured for the channel spacing on
each channel (Personality).
4 TRANSMISSION/ RECEPTION
4.2 Transmit Power
Common FUNC (K, F)/Ver 2.20 80
