Optimizing Various Signal Levels
The DI Level, DEO Level, and AFO Level can be configured using KPG-D1/ D1N.
DI Level
DI Level is the input signal level of the DI port available on the D-sub 25-pin connector of the transceiver. The input signal
level can be optimized according to the devices that are connected to the transceiver.
DEO Level
DEO Level is the output signal level of the DEO port available on the D-sub 25-pin connector of the transceiver. The output
signal level can be optimized according to the devices that are connected to the transceiver.
AFO Level
AFO Level is the output signal level of the AFO port available on the D-sub 25-pin connector of the transceiver. The output
signal level can be optimized according to the devices that are connected to the transceiver.
Configuration using KPG-D1/ D1N
0
Configuring DI Level (
Transceiver Settings > Extended Function > Mobile Function)
0
Configuring DEO Level ( Transceiver Settings > Extended Function > Mobile Function)
0
Configuring AFO Level (
Transceiver Settings > Extended Function > Mobile Function)
11 EXTERNAL PORTS
11.2 D-sub 25-pin Connector
Common FUNC (K, F)/Ver 2.20 225
