Kenwood NX-5200K3 Common Function Reference

11.2
D-sub 25-pin Connector
Supported Models: Mobile
For Mobile, the transceiver is equipped with function ports (AUX Input/ AUX Output) that can be programmed for use with
the D-sub 25-pin connector located on the rear panel of the transceiver.
Available Functions for AUX Input Ports
This section describes each function that can be assigned to AUX Input ports.
Depending on a function assigned to an AUX Input port, the function immediately functions if the AUX Input port is active
when
the transceiver is turned ON. In addition, depending on the function assigned to an AUX Input port, the function does
not function when the transceiver is in the Radio Inhibit state. Refer to the following table for how the function functions
depending on the transceiver status.
Table 11-3 Behavior of Each Function Depending on the Transceiver Status
Function
Transceiver Status
When the transceiver
is turned ON
While the transceiver
is in the Stun state
While the transceiver is
in the Radio Inhibit state
External PTT (Voice) No No No
External PTT (Data) No No No
Data PTT No No No
External PTT (PA) No No No
Channel Select A to Channel Select D Yes
*1 *1
DTC Yes
*1 *1
Speaker Mute Yes Yes
*1
Mic Mute Yes Yes
*1
External Monitor Yes Yes
*1
External Hook Yes Yes
*1
External Speaker Yes Yes
*1
Emergency Yes No No
AUX Input Status Message 1 to AUX Input
Status Message 3
No No No
Scan Yes
*1 *1
Call 1 to Call 6 No No No
Light Sense Yes Yes
*1
Zeroize Yes No No
Scrambler/ Encryption Yes
*1 *1
*1
The function functions when the Stun or Radio Inhibit state is reset.
Yes: functions, No: does not function
Configuration using KPG-D1/ D1N
Assigning functions to the AUX Input port ( Transceiver Settings > Extended Function > AUX)
11 EXTERNAL PORTS
11.2 D-sub 25-pin Connector
Common FUNC (K, F)/Ver 2.20 211
