5.13
Displaying a Bitmap Image When the Transceiver is Turned ON
(Custom Start-up Screen)
Custom Start-up Screen is the function to display a bitmap image when the transceiver is turned ON. The image of a
company
name, logo, or simple message can be converted into bitmap image data and it can be displayed for 2 sec when
the transceiver is turned ON. (Refer to Turning the Transceiver ON.)
Bitmap images of the following sizes can be used:
Portable: 240 horizontal dots, 180 vertical dots
Mobile (KCH-19 (Basic Panel)): 422 horizontal dots, 154 vertical dots
Mobile (KCH-20R (Featured Panel)): 400 horizontal dots, 240 vertical dots
Mobile (KCH-21R (Handheld Control Head)): 240 horizontal dots, 180 vertical dots
An image with 65,536 colors can be displayed.
Note
Only image files (extension: .bmp) edited in Windows Paint can be used.
Configuration using KPG-D1/ D1N
Configuring Custom Start-up Screen ( Transceiver Settings > Optional Features > Optional Features 1 > Power-on)
5 INDICATION AND DISPLAY
5.13 Displaying a Bitmap Image When the Transceiver is Turned ON (Custom Start-up Screen)
Common FUNC (K, F)/Ver 2.20 104
CONTENTS INDEX
To Next Page
